Wet Area End Fittings For Fiber Optics

UFO P4G Submersible Fitting

A small stainless steel paver end fitting with clear glass window for sheathed polymer fiber of 1.5mm to 2mm active diameter.
Comes fitted with a nickel plated brass gland to allow for connection to the fiber and to prevent moisture ingress below the lens.
The P4G is suitable for use in swimming pool floors and other wet areas to give a starfield like effect. Can also be used on pathways and other paved areas to give a similar effect.
TECHNICAL INFORMATION
Glass10mm (0.39") clear or frosted flat window
Beam Angle20° - 50°
Material316 stainless steel
Available FinishesNatural stainless steel
Weight12g (0.03lb)
Mounting Hole Size12.5mm (0.49")
Fiber Sizes1.5mm (0.06") to 2mm (0.08") diameter
Ordering CodeClear Glass: UFO P4G-SS-N-C
Frosted Glass: UFO P4G-SS-N-F
