UFO LD5 LED Downlight Fitting

Supplied with a warm white or neutral white LED light and a CRI of >95 that ensures colours are shown in their true light, the LD5 is particularly useful for illuminating static objects within display cabinets and fixtures due to its adjustable nature.

Integral to the front of the fitting is a slim snoot that can tilt up to 35°, allowing you to focus a concentrated beam of light in almost any direction required, whilst reducing glare from the LED.

In addition to be being installed in ceilings, the aluminum fitting is also suitable for mounting in the base of display cabinets and projecting light upwards. It is supplied with a back nut to allow for secure installation in a recess and can be finished in a range of colours to match your display cabinet or décor requirements.

UFO LD5 DOWNLIGHT / GENERAL INFORMATION
Illuminator	White Light LED
Operating Environment	Indoor use only
Material	Aluminum
Available Finishes	Black body with black, white, silver or custom RAL
Dimensions	40mm (1.58") Diameter x 31mm (1.22") Length
Securing Method	Secured through surface with retaining ring. 34mm cutout required.

UFO LD5 DOWNLIGHT / ARTICULATION
Rotation	360°
Tilt	35°

UFO LD5 DOWNLIGHT / LED ARRAY DATA
LED Type	Osram Oslon Square on 16mm Diameter PCB
LED Life (L70, B10)	>50,000 Hours
Fitting Drive Current	350mA
Power Consumption	1W @ 350mA
Color Temperature Options	2700K, 3000K, 4000K
CRI (typical)	2700K: >98 3000K: >98 4000K: >97
LED Luminous Efficacy	(based on 23° lens and 350mA driver) 2700K: 55lm/W 3000K: 58lm/W 4000K: 63lm/W
Driver Type	Constant Current LED Driver Required

UFO LD5 DOWNLIGHT / OPTICS DATA
Optics Family	Carclo
Available Optics	16° / 23° / 36° / 61°

UFO LD5 DOWNLIGHT / DRIVER DIMMING OPTIONS
Driver Specific	No Dimming 0-10V DALI DMX Mains Local Potentiometer Dimming Remote Potentiometer Dimming
